Smart PDUs Overview

Vericom’s rackmount Smart Power Distribution solutions are engineered to efficiently deliver power to your equipment, are exceptionally reliable and user friendly, and offer the best price-performance ratio in the industry. These Smart PDUs are suitable for helping small, midsize, enterprise, and colocation data centers increase efficiency, raise productivity, and improve reliability. Each PDU is thoroughly tested before shipment and conforms to the most stringent industry standards.

Our Smart PDU portfolio includes VPD, VPS, VPM, and VPO series smart PDUs. These PDUs include the most advanced hot-swappable, field replaceable SNMP IP controller in the industry. Standard features include dual Gigabit Ethernet ports, OLED full color screen, cascading multi-sensor ports, enhanced security, sophisticated alarming and power monitoring across the entire power chain. This portfolio offers a comprehensive range of feature sets focusing on advanced outlet metering and control.

Resources

Feature Summary	VPD Series Advanced Inlet Monitoring	VPS Series Inlet Monitoring + Outlet Switching	VPM Series Inlet Monitoring + Outlet Switching
Mechanical Features Ultra light aluminum chassis Multiple mounting options Low profile hydraulic magnetic breakers 10KA Icn
Inlet Energy Metering PDU input energy metering kWh PDU input power measurements (W, VA, VAR) PDU input (A, V, PF, HZ) measurements Circuit breaker monitoring Residual current monitoring (optional) 3 phase balance indicator
Security Management Memory logs for historical data and graphics Customizable user and alarm thresholds
SNMP Controller PDU cascading / daisy chaining (up to 16 PDUs) Hot swappable and field replaceable controller Double gigabit ethernet port Controller power share / Network Failsafe
Outlet Control Remote On/ Off by individual outlet or groups Power On/ Off delay Sequential Startup Assignable user level security Individual LED outlet status indicator	Feature Not Included In This Series		Feature Not Included In This Series
Outlet Metering Energy usage (kWh) Power Measurements (W, VA, VAR) PDU output (A, V, PF, HZ) measurements	Feature Not Included In This Series	Feature Not Included In This Series
Environmental Metering Environmental sensor temp & humidity Cascading / daisy chaining (up to 8 total EMD sensors) Input for 2 additional sensors on each EMD sensor: • Door contact • Smoke detection • Vibration • Motion sensor • Flood detection Customizable user and alarm thresholds
Network & Security DHCP, IPv4 and IPv6, DNS, http / https, SSHv.2, SNMP, v1 / v2c / v3, SNMP TRAPS / SETS / GETS, SMTP, Modbus, Telnet, TCP, RADIUS, Syslog,TLS 1.2, SNTP

These PDUS are available in Single Phase Horizontal, Single Phase Vertical, or Three Phase Vertical and are offered in multiple configurations to suit your specific power distribution requirements. Choose from one of our standard configurations or contact us to have a PDU custom built to your specifications.
